SAS9305-24I Technical Specifications
Broadcom Lsi 12gb/s 24-port Internal Pci Express 3.0 Sas Non-raid Controller
Brand Name: Broadcom
Model Number or SKU# SAS9305-24I
Product Type: Controller
Product Name: SAS-SATA
Main Specifications
Host Bus Type: X8 Lane Pci Express 3.0
Physical Dimensions: 2.7 X 6.6
Devices Supported: 1024 Non-raid Sata/sata Devices Per Controller
Internal Connectors: 6 Mini-sas Hd Sff8643
Internal Ports: 24
Operating Temperature: 0°c To 55°c
Operating Voltage: +12v +/-8%, 3.3v +/-9%
Os Support: Microsoft Windows, Linux (oracle, Suse, Red Hat), Solaris,
vmware, Freebsd, Centos, Canonical
Cable Support: Passive Copper, Active Optical
I/o Controller: Sas3224
