SAS9200-8E 56 Technical Specifications
Lsi Logic 8 Ports Serial Attached SCSI (SAS) 6GBPS Serial Advanced Technology Attachment (SATA) 6GBPS Peripheral Component Interconnect Express (PCI-E) Low Profile Host Bus Adapter
Manufacturer: LSI Logic
Part Number or SKU# SAS9200-8E
Product Type: SAS Controller
Technical Specifications
Storage Connectivity: 8 Ports
Data Transfer Rates: 6 Gb/s
Host Bus: X8 Lane, PCI Express 2.0 Compliant
Form Factor: Low Profile
Connectors: Two Mini-SAS External Connectors (SFF8088)
Controller Type: LSI SAS2008 / Fusion MPT 2.0
Storage Connectivity Data Transfer Rates: 8 Ports, 6 Gb/s, SAS 2.0 Compliant
Host Bus: X8 Lane, PCI Express 2.0 Compliant
PCI Data Burst Transfer Rates: Half Duplex, x8 PCIe, 4000 Mb/s, +12V ±10%
Cable Support: Passive Copper
PCI Card Type: 3.3V Add-In Card
Operating Voltage: +12V +/-8%, 3.3V +/-8%
PCI Power (Nominal): 8W Typical (Airflow Min 200 LFM)
Device Support: 512 Non-RAID SAS/SATA Devices
