RB750r2 Technical Specifications
MikroTik RouterBOARD 750r2 hEX lite Complete with enclosure, power supply
Manufacture Part Number : RB750r2
Manufacture : MikroTik
Number of Ports : 10/100 Ethernet ports 5
Switch chip model: QCA9531-BL3A-R
PoE In: Yes
Supported input voltage: 10V – 28V
Operating System: RouterOS
Max Power consumption: 2W
Architecture MIPSBE
CPU QCA9533
CPU core count 1
CPU nominal frequency 850 MHz
Switch chip model QCA9533
Dimensions 113x89x28mm. Weight without packaging and cables: 129g
RouterOS license 4
Operating System RouterOS
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
MTBF Approximately 100’000 hours at 25C
Tested ambient temperature -40°C to 70°C
Details
Number of DC inputs 2 (DC jack, PoE-IN)
DC jack input Voltage 6-30 V
Max power consumption 2 W
Cooling type Passive
PoE in Passive PoE
PoE in input Voltage 6-30 V
