RB2011iLS-IN Technical Specifications
MikroTik RouterBOARD with Case Power Supply and Fiber-Enabled
Manufacture Part Number : RB2011iLS-IN
Manufacture : MikroTik
CPU: Atheros AR9344 600MHz
RAM: 64MB DDR SDRAM on board memory
Architecture: MIPS-BE
LAN ports: 5
MiniPCI: 0
Integrated Wireless: No
PoE: 8-30V DC on Ether1
Voltage Monitor: No
Temperature sensor: No
Operating System: RouterOS
Temperature range: -30 .. +70C
RouterOS License: Level4
Number of DC inputs 2 (DC jack, PoE-IN)
DC jack input Voltage 8-30 V
Max power consumption 18 W
Max power consumption without attachments 6 W
PoE in Passive PoE
PoE in input Voltage 8-30 V
Ethernet
Details
10/100 Ethernet ports 5
10/100/1000 Ethernet ports 5
PoE-out
Details
PoE-out ports Ether10
PoE out Passive PoE
Max out per port output (input 18-30 V) 510 mA
Max total out (A) 510 mA
