QSFP-40G-LR Technical Specifications
Alcatel-Lucent four channel 40 Gigabit Optical Transceiver
Form Factor: QSFP Plus
Data Rate: 40Gb/s
Wavelength: 1310nm
Connector: LC Duplex
Cable Type: SMF
Reach Distance: 10KM
Operating Temperature Range: 0 ºC to 70ºC
Digital Optical Monitoring (DOM): Supported
Applications: 40GBase-LR4
Brand Name Alcatel-Lucent
Product Type QSFP+
Technical Information
Application/Usage Optical Network
Data Networking
Interfaces/Ports
Interfaces/Ports Details 1 x LC Duplex 40GBase-LR4 Network
Media & Performance
Media Type Supported Optical Fiber
Fiber Mode Supported Single-mode
Ethernet Technology 40 Gigabit Ethernet
Network Technology 40GBase-LR4
Physical Characteristics
Form Factor Hot-swappable
Height 0.3″
Width 0.7″
Depth 2.4″
