QFX5220-32CD-D-AFI Technical Specifications
Juniper QFX Series QFX5220-32CD switch 32 ports managed rack mountable
Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks QFX Series
Model :QFX5220-32CD
Packaged Quantity :1
Chassis
Airflow Direction :Back to front airflow
Processor
Type :Xeon D-1518, Xeon
Processor Number :D-1518
Installed Qty :1
Manufacturer :Intel
Performance
Performance :Forwarding capacity: 80000000 packets per second, Switching throughput: up to 12.8 Tbps
Capacity
Capacity :Maximum member ports per LAG: 64, Firewall egress filters (VACL, PACL rules): 512, Firewall egress filters RACL rules: 2558, Packet buffer size: 128 MB, Firewall ingress filters(RACL, VACL, PACL rules): 768, VLAN IDs: 3968, IPv4 routes (Unicast): 3800000, IPv6 routes (Unicast): 130000, MPLS labels: 16000, ARP entries: 32000, GRE tunnels: 2000, LAG groups: 128
