QFX3500-ACRB-BNDL Technical Specifications
Juniper Networks QFX Series QFX3500 Switch managed rack mountable
Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks QFX Series
Model :QFX3500 Switch
Packaged Quantity :2
Chassis
Airflow Direction :Back to front airflow
Built-in Devices :Status LCD
Performance
Performance :Switching capacity: 960 Mbps, Throughput: 1.28 Tbps
Capacity
Capacity :IPv4 routes: 8000, Multiple Spanning Tree Protocol instances: 64, Layer 2 multicast groups: 3500, Virtual interfaces (VLANs): 4095, Firewall policies: 1500, VLAN Spanning Tree Protocol instances: 253
Networking
Type :Switch
Subcategory :Network hubs and switches
Subtype :10 Gigabit Ethernet
Form Factor :Rack-mountable
Advanced Switching :Layer 3
Routing Protocol :PIM-SM, CIDR, OSPF, Bidirectional Forwarding Detection (BFD), ECMP, IGMP, IGMPv2, IS-IS, BGP-4, RIP-2, MSDP, RIP, OSPFv2, VRRP, IGMPv3, BGP
MAC Address Table Size :120000 entries
Jumbo Frame Support :9216 bytes
Manageable :Yes
