QDD-2X100-SR4-S Technical Specifications
Cisco 2x100G QSFP-DD Transceiver
Brand: Cisco
Part Number: QDD-2X100-SR4-S
Condition: Factory New Sealed
Availability: In Stock
Product description: Cisco 2x100G QSFP-DD Transceiver, 2X 100GBASE-SR4, MPO-24 MMF, 100m OM4
Nominal wavelength: 850nm
Cable type: Ribbon MMF
Cable distance: 100m
Pull tab color: Beige
Nominal rate: 2x100GE
High-speed electrical: 2x 100G CAUI-4
Average Transmit Power per lane (dBm) min: -8.4
Average Transmit Power per lane (dBm) max: +2.4
Average Receive Power per lane (dBm) min: -10.3
Average Receive Power per lane (dBm) max: +2.4
Maximum Supported Insertion Loss (IL) (dB): 1.9
Max power consumption (W): 12W
Operation temperature: 0 to 75°C
Storage temperature: -40 to 85°C
