PSDIN-48-240W Technical Specifications
Tycon Power 48V 240W DIN Rail Industrial Power Supply
Brand: Tycon Systems
Width: 5.30 (in)
Height: 4.80 (in)
Depth: 1.80 (in)
Weight: 2.00 LBS
Input Operating Range: 90-264VAC ; 47-63Hz
Input In-rush Current: 35A Max
Input Current: 4.4A @ 115VAC ; 2.20A @ 230VAC
Output Voltage: 47~ 56VDC (adjustable)
Maximum Output Power: 240W
Peak Power (10sec @ 220VAC): 360W
Voltage Overshoot: <5%
Ripple / Noise: 100mV Peak
Efficiency: 90% Minimum
Dielectric Strength: 1500V rms , 1 min, 10mA Max
Insulation Resistance: 10M Ohms
Protection: Short Circuit, Over-Voltage, Over-Current, Over Power
Alarm Output: (“DC” and “OK”) 1A @ 30VDC, 0.5A @ 125VAC. DC OK = Closed, DC Fault = Open
Safety Standards: GB4943 / EN60950-1
EMI Standards: FCC PART 15 CLASS B, EN55022, EN55024
Storage Temp: -40°C to 85°C (-40°F to 185°F)
MTBF: 200,000 hrs
Altitude: 2000m (6562ft)
Case Size: 135 x 121 x 45mm (5.3 x 4.8 x 1.8”)
