Refurbished PRO-H410M-C/CSM Technical Specifications
ASUS Pro H410M-C/CSM LGA 1200 Micro ATX Motherboard
CPU
Chipset Intel H410
CPU Socket LGA 1200
Back Panel I/O
USB 2 x USB 3.1 / USB 3.2 Gen 1 Type-A
2 x USB 2.0 Type-A
Display 1 x HDMI
1 x DVI-D
1 x VGA
Audio 3 x 3.5 mm
Ethernet / Controller 1 x Intel I219V Gigabit
PS/2 2 x PS/2
Legacy 1 x Serial
Memory
Memory Slots 2 x 288-Pin
Memory Support DDR4 2133, 2400, 2666, 2800, 2933 MHz
Maximum Capacity 64 GB
Channel Architecture Dual Channel
Storage Expansion
SATA 4 x SATA III
M.2 1 x M Key 2242, 2260, 2280 (PCIe (Unspecified), SATA (Unspecified))
Internal I/O
Expansion Slots 1 x PCIe 3.0 x16 (x16 mode)
1 x PCIe 3.0 x1
2 x PCIe
USB 1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port)
2 x USB 2.0 Header (Supports 4 USB Type-A Port)
Air Cooling 1 x 4-Pin CPU
1 x 4-Pin System
Power Connectors 1 x 24-Pin Mainboard
1 x 8-Pin ATX
Security Chassis Intrusion, TPM Module
Diagnostics 2-Digit Debug LED, Clear CMOS
Legacy 1 x Serial
BIOS
ROM 128 Mb
Front Panel I/O
I/O Connection Headers USB 3.1 / USB 3.2 Gen 1
Audio
Audio Codec Realtek ALC887 (7.1-Channel)
Software
Supported Operating Systems Windows 10 (64-Bit)
Physical
Form Factor Micro-ATX
Dimensions 9.6 x 8.2″ / 24.4 x 20.8 cm
