PRIME X570-P Technical Specifications
ASUS AM4 with PCIe Gen4, Dual M.2 HDMI, SATA 6Gb/s USB 3.2 Gen 2 ATX Motherboard
Model
Brand
ASUS
Model
PRIME X570-P
Supported CPU
CPU Socket Type
AM4
CPU Type
AMD AM4 Socket 3rd and 2nd AMD Ryzen / 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
Chipsets
Chipset
AMD X570
Memory
Number of Memory Slots
4×288pin
Memory Standard
3rd Gen AMD Ryzen Processors
4400(O.C.)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 MHz Un-buffered Memory
2nd Gen AMD Ryzen Processors
DDR4 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3200(O.C.)/ 3000(O.C.)/ 2933/ 2800/ 2666/ 2400/ 2133 MHz Un-buffered Memory
2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
DDR4 3200(O.C.)/ 3000(O.C.)/ 2933/ 2800/ 2666/ 2400/ 2133 MHz MemoryMaximum Memory Supported
128GB
Channel Supported
Dual Channel
Expansion Slots
PCI Express 4.0 x16
3rd Gen AMD Ryzen Processors
1 x PCIe 4.0 x16 (x16 mode)
2nd Gen AMD Ryzen Processors
1 x PCIe 3.0 x16 (x16 mode)
2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
1 x PCIe 3.0 x16 (x8 mode)
AMD X570 chipset
1 x PCIe 4.0 x16 (max at x4 mode)
PCI Express x1
3 x PCIe 4.0 x1
Storage Devices
SATA 6Gb/s
6 x SATA 6Gb/s
M.2
3rd Gen AMD Ryzen Processors:
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support
2nd Gen AMD Ryzen / 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors:
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices support
AMD X570 chipset:
1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280/22110 (PCIE 4.0 x4 and SATA modes) storage devices support
SATA RAID
0/1/10
Onboard Video
Onboard Video Chipset
Integrated Graphics in the 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics Processors
VGA output support: HDMI port
– Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz
Onboard Audio
Audio Chipset
Realtek S1200A High Definition Audio CODEC
Audio Channels
8 Channels
* Choose the chassis with HD audio module in front panel to support 8-channel audio output.
Onboard LAN
LAN Chipset
Realtek RTL8111H
Max LAN Speed
10/100/1000Mbps
Rear Panel Ports
Back I/O Ports
1 x PS/2 keyboard/mouse combo port(s)
1 x HDMI
1 x LAN (RJ45) port(s)
2 x USB 2.0
3 x Audio jack(s)
2 x USB 3.2 Gen 1 (up to 5Gbps) ports Type-A
4 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A*)
* The USB ports under the LAN port can run at USB 3.2 Gen 2 speeds with 3rd Gen AMD Ryzen Processors
