PRIME B460M-A Technical Specifications
ASUS LGA 1200 Micro-ATX Motherboard
CPU
Chipset Intel B460
CPU Socket LGA 1200
Back Panel I/O
USB 4 x USB 3.1 / USB 3.2 Gen 2 Type-A
2 x USB 2.0 Type-A
Display 1 x HDMI
1 x DVI-D
1 x VGA
Audio 3 x 3.5 mm
Ethernet / Controller 1 x Realtek RTL8111H Gigabit
PS/2 1 x Combo
Memory
Memory Slots 4 x 288-Pin
Memory Support DDR4 2133, 2400, 2666, 2800, 2933 MHz
Maximum Capacity 128 GB
Channel Architecture Dual Channel
ECC Support Non-ECC Unbuffered
Storage Expansion
SATA 6 x SATA III
M.2 1 x M Key 2242, 2260, 2280 (PCIe (Unspecified), SATA (Unspecified))
1 x M Key 2242, 2260, 2280, 22110 (PCIe 3.0 x4)
Optane Memory Support Yes
RAID Support RAID 0, 1, 5, 10
Internal I/O
Expansion Slots 1 x PCIe 3.0 x16 (x16 mode)
2 x PCIe 3.0 x1
USB 1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port)
2 x USB 2.0 Header (Supports 4 USB Type-A Port)
Air Cooling 1 x 4-Pin CPU
3 x 4-Pin System
Power Connectors 1 x 24-Pin Mainboard
1 x 8-Pin ATX
Security Chassis Intrusion, TPM Module
LED Header 2 x RGB
Audio 1 x S/PDIF
Diagnostics Clear CMOS
BIOS
ROM 128 Mb
Front Panel I/O
I/O Connection Headers USB 3.1 / USB 3.2 Gen 1
Audio
Audio Codec Realtek ALC887 (7.1-Channel)
Software
Supported Operating Systems Windows 10 (64-Bit)
