PB-4OC3-1OC12-SON2-SFP Technical Specifications
Juniper Networks 4 Port OC3/STM1 or 1 Port OC12/STM4 Rate Selectable
Manufacturer Juniper Networks, Inc
Manufacturer Part Number PB4OC31OC12SON2SFP
Brand Name Juniper
Product Type Interface Module
Technical Information
Application/Usage Data Networking
Media & Performance
Media Type Supported Optical Fiber
Fiber Mode Supported Multi-mode, Single-mode
Network Technology OC-3/STM-1, OC-12/STM-4
Maximum Data Transfer Rate 622.08 Mbit/s
I/O Expansions
Number of Total Expansion Slots 4
Expansion Slot Type SFP
Miscellaneous
Additional Information
Possible Interface:
4 x OC-3/STM-1
1 x OC-12/STM-4
OC-3/STM-1:
Distance support MMF: 2km
Distance support SMF: 40km
Wavelength: 1263 through 1360nm
OC-12/STM-4:
Distance support: 40km
Wavelength: 1280 through 1335nm
Compatibility
M40e Router
M120 Router
M320 Router
T320 Router
T640 Router
T1600 Router
