ONENTWK-EN-07-10 Technical Specifications
Cisco ONE Catalyst 4500 Series Platform
Product Line Cisco ONE Catalyst
Product Series C4500
Product Type Switch Chassis
Device Type Switch – 192 ports – managed – with 2x SUP8e, 4x 4748-UPoE
Enclosure Type Rack-mountable 11U
Subtype Gigabit Ethernet
Ports 192 x 10/100/1000 (PoE) + 16 x SFP+
Power Over Ethernet (PoE) PoE+
Performance Switching capacity: 928 Gbps ¦ Per-slot switching capacity: 48 Gbps ¦ IPv6 routing: 125 Mbps ¦ IPv4 routing: 250 Mbps
Capacity QoS hardware entries: 128000 ¦ Security services entries: 128000 ¦ Virtual interfaces (VLANs): 4094 ¦ ARP entries: 47000 ¦ IPv6 routing table entries: 128000 ¦ IPv4 routing table entries: 256000 ¦ Spanning Tree Protocol instances: 10000 ¦ Switched virtual interfaces (SVIs): 4094 ¦ NetFlow entries: 128000
MAC Address Table Size 55K entries
Routing Protocol PIM-SM, PIM-DM, PIM-SSM
Remote Management Protocol RMON 1, RMON 2, CLI
