IBM x3650 Technical Specifications
M5 5462 Intel Xeon E5-2690V3 2.6GHz 64GB RAM Server
Processor
Clock Speed: 2.6 GHz
Installed Qty: 2
Manufacturer: Intel
Max Supported Qty: 2
Max Turbo Speed: 3.5 GHz
Number of Cores: 12-core
Processor Main Features: Intel Turbo Boost Technology 2
Processor Number: E5-2690V3
Server Scalability: 2-way
Type: Xeon
Upgradability: Upgradable
Audio Input
Type: None
Bay Provided
Form Factor: 2.5″
Free Qty: 8
Total Qty: 8
Form Factor: 5.25″
Free Qty: 1
Total Qty: 1
Cabinet
Chassis Built-in Devices: Status LCD
Cache Memory
Installed Size: 60 MB
Per Processor Size: 30 MB
Display
Type: None.
Header
Brand: Lenovo
Compatibility: PC
Localization: English
Manufacturer: Lenovo ESG TopSeller Servers
Model: 5462
Packaged Quantity: 1
Product Line: Lenovo System x3650 M5
Input Device
Type: None
Interface Provided
Location: 2 front, 2 rear
Qty: 4
Type: USB 2.0
Location: 1 front, 1 rear
Qty: 2
Type: VGA
Type: USB 3.0
Type: LAN (Gigabit Ethernet)
Qty: 1
Type: Management
Location: 1 internal
Type: USB
Mainboard
Chipset Type: Intel C612
Processor Socket: LGA2011-v3 Socket
Miscellaneous
Features: Administrator password , Power-on password
Height (Rack Units): 2
Manufacturer Selling Program: TopSeller
Product Color: Black
Networking
Data Link Protocol: Ethernet , Fast Ethernet , Gigabit Ethernet
Ethernet Controller(s): Broadcom BCM5719
Ethernet Ports: 4 x Gigabit Ethernet
Form Factor: Integrated
Remote Management Controller: Integrated Management Module v2 (IMM2)
OS Provided
Type: No operating system
Power Device
80 PLUS Certification: 80 PLUS Platinum
Frequency Required: 50/60 Hz
Installed Qty: 1
Max Supported Qty: 2
Nominal Voltage: AC 120/230 V
Power Provided: 900 Watt
Power Redundancy: Optional
Power Redundancy Scheme: 1+1 (with optional power supply)
Type: Power supply – hot-plug
Printer
Type: None
RAM
Configuration Features: 4 x 16 GB
Data Integrity Check: ECC
Features: Memory Mirroring , Memory Sparing , Mixing of different types of memory modules is not supported , Slots 13 – 24 are available in two-processor configuration only
Form Factor: DIMM 288-pin
Installed Size: 64 GB
Memory Speed: 2133 MHz
Technology: DDR4 SDRAM
Slot Provided
Free Qty: 20
Total Qty: 24
Free Qty: 0
Total Qty: 2
Free Qty: 1
Total Qty: 1
Optical Storage (2nd)
Drive Type: No optical drive
Type: None
Storage Controller
Form Factor: Plug-in card
Installed Qty: 1
Interface Type: Serial ATA-600 / SAS 3.0
RAID Level: RAID 0 , RAID 1 , RAID 10
Storage Controller Name: ServeRAID M5210
Type: Serial Attached SCSI
Storage Controller (2nd)
Type: None
Storage Removable
Type: None
System
Embedded Security: Trusted Platform Module (TPM 2.0) Security Chip
Hard Drive Capacity: 0 GB
Type: Server
Video Output
Form Factor: Integrated
Graphics Processor Series: Matrox G200
Graphics Processor Vendor: Matrox G200eR2
Video Interfaces: VGA
Hard Drive
Type: No HDD
Hard Drive (2nd)
Type: None
Hard Drive (3rd)
Type: None
Optical Storage
Drive Type: No optical drive
Type: None
RAM Supported
Max Size: 1.5 TB
Registered or Buffered: Load-Reduced
Max Size: 384 GB
Registered or Buffered: Registered
Video Memory
Installed Size: 16 MB
