N9K-C9504-B3-E Technical Specifications
Cisco ONE Nexus 9504 Bundle Switch Managed Rack Mountable
Brand: Cisco
Product Line: Cisco Nexus
Model: 9504 Chassis Bundle
Manufacturer: Cisco Systems
Network & Communication
Advanced Switching: Layer 3
Form Factor (Hubs & Switches): Rack-mountable
Manageable: Yes
Product Type: Switch
Subcategory: Network hubs and switches
Expansion Slots
Expansion Slots: 8 (total) / 2 (free) x expansion slot
Power
Features: Front-to-rear airflow
Frequency: 50 – 60 hertz
Hot-Plug: Hot-plug
Power Provided: 3000 watt
Power Supplies Installed: 3
Technical Information
Max Operating Temperature: 40 degree Celsius
Max Storage Temperature: 70 degree Celsius
Min Operating Temperature: 0 degree Celsius
Min Storage Temperature: -40 degree Celsius
Operating Humidity: 5 – 95% (non-condensing)
Dimensions & Weight
Height: 20.36 centimetre
Height (Rack Units): 7
Width: 44.5 centimetre
Depth: 76.2 centimetre
Physical Characteristics
Color Category: Gray
