Refurbished N7K-C7004-S2E-R Technical Specifications
Cisco Nexus 7004 Bundle Switch
Brand :Cisco
Product Line :Cisco Nexus
Model :7004 Bundle
Bundled with :2 x Cisco Nexus 7000 Series Supervisor 2 Enhanced Module
Packaged Quantity :1
Chassis
Installed Devices / Modules Qty :2
Supported Devices / Modules Qty :4
Processor
Type :Xeon
Installed Qty :2
Manufacturer :Intel
Clock Speed :2.13 GHZ
RAM
Technology :DDR3 SDRAM
Installed Size :64 GB
Flash Memory
Installed Size :16 GB, 16 GB
Networking
Type :Switch
Subcategory :Network hubs and switches
Form Factor :Rack-mountable
Advanced Switching :Layer 3
Manageable :Yes
Remote Management Protocol :CLI, SNMP
Features :Modular design
Expansion Slots
Expansion Slots :4 (total) / 2 (free) x CompactFlash Card, 4 (total) / 2 (free) x expansion slot
Interface Provided
Interfaces :2 x console – RJ-45 management, 2 x console RJ-45, 6 x USB
Power Device
Type :Internal power supply
Hot-Plug :Hot-plug
Installed Qty :0
Max Supported Qty :2
Miscellaneous
Height (Rack Units) :7
Compliant Standards :BSMI CNS 13438 Class A, CISPR 22 Class A, CISPR 24, EMC, EN 300 386, EN 55022 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN300-386, EN50082-1, EN55024, ETSI, FCC CFR47 Part 15, FCC Class A certified, ICES-003 Class A, IEC 60950-1, NEBS level 3, RoHS 5/6, UL 60950-1, VCCI Class A ITE
Dimensions & Weight
Width :17.4 inch
Depth :24.5 inch
Height :12.2 inch
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Min Storage Temperature :-40 degree Fahrenheit
Max Storage Temperature :158 degree Fahrenheit
Humidity Range Operating :5 – 90% (non-condensing)
Humidity Range Storage :5 – 95% (non-condensing)
