MTFDDAK7T6TDC Technical Specifications
Micron 7.68TB 5200 Eco 2.5 inch TLC 6Gb/s SATA SSD
Manufacturer: Micron
Product Type: Solid State Drive
Interface: SATA-6GBPS
Serial ATA-600
Sector Size: 512 / 512e
Sustained Throughput: 540/520
Average Seek Time: 40 µs
SSD Endurance DWPD: Enterprise Read Intensive
Technical Information of 7.68TB SSD
Form Factor : 2.5inch 7mm
Storage Capacity : 7.68TB/7680GB
Mttf : 3.0 Million Device Hours
Average Latency 40 µs
Bytes per Sector 512
Data Transfer Rate 600 Mbps
Internal Data Rate 540 Mbps
Internal Data Rate (Write) 520 Mbps
Manufacturing Process 16nm
NAND Flash Memory Type 3D Triple-Level Cell (TLC)
Non-Recoverable Errors/Td> 1 per 10^15
Product Dimensions And Weight
Width: 2.7 Inch
Depth: 4 Inch
Height: 0.3 Inch
Weight: 0.12 lbs
Performance for SATA 6GBPS Solid State Drive
Humidity Range Operating 5 – 95% (Non-Condensing)
Max Operating Temperature 158°F
Min Operating Temperature 32°F
4KB Random Read 95000 IOPS
4KB Random Write 32000 IOPS
Sequential Read : Up To 540 MBPS
Sequential Write : Up To 520 MBPS
Random 70/30 R/W (4KB Transfer) : 26k IOPS
Compliant Standards of Enterprise Read Intensive SSD
AS/NZS CISPR 32 Class B
BSMI CNS 13438
