MSN2410-BB2R Technical Specifications
Mellanox Switch-IB 2 SB7800 Switch 6 ports Smart Rack-mountable
Brand: Mellanox
Product Line: Mellanox Switch-IB 2
Model: SB7800
Manufacturer: Nvidia Corp
Network & Communication
Compliant Standards: IBTA 1.21, IBTA 1.3
Form Factor (Hubs & Switches): Rack-mountable
Manageable: Yes
Ports: 36
Product Type: Switch
Remote Management: CLI, HTTP, SNMP 1, SNMP 2, SNMP 3
Smart: Yes
Status Indicators: Error, Fan, Link/activity, Power
Subcategory: Network hubs and switches
Switching Type: InfiniBand
Connectivity
Port Quantity: 36
Port Type: 100 Gigabit QSFP28
Power
Frequency: 50/60 hertz
Power Consumption Operational: 281 watt
Power Supplies Installed: 2
Power Supplies Supported: 2
Redundant Power Supply: Yes
Redundant Power Supply Supported: 1+1
Technical Information
Humidity Range Storage: 10 – 90% (non-condensing)
Max Operating Temperature: 113 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Min Operating Temperature: 32 degree Fahrenheit
