LSI00344 Technical Specifications
LSI Logic SAS 9300-8i 8-Port SAS 12Gbps / SATA 6Gbps PCI Express 3.0 x8 Low Profile HBA Controller Card
Manufacturer Part Number LSI00344
Brand Name LSI Logic
Product Type SAS Controller
Technical Information
Host Interface PCI Express 3.0 x8
Controller Type 6Gb/s SAS
RAID Supported No
Interfaces/Ports
Total Number of SAS Ports 2
Number of SAS Ports (Internal) 2
SAS Connector Details 2 SFF-8643
Physical Characteristics
Height 2.7″
Width 6.6″
Form Factor Plug-in Card
Weight (Approximate) 1.32 lb
Miscellaneous
Platform Supported PC
