L29195-001 Technical Specifications
HP 512GB SATA 6Gbps M.2 2280 Internal Solid State Drive (SSD)
Manufacturer: HP
Brand: HP
Product Type: Internal Solid State Drive (SSD)
Storage Capacity
Total Capacity: 512GB
Form Factor
Physical Size: M.2 2280
Dimensions: 22mm (Width) x 80mm (Length)
Thickness: 3.5mm (Approximate)
Weight: 7g (Approximate)
Interface
Interface Type: SATA III (6Gbps)
Connector Type: M.2 B-key
Performance
Maximum Sequential Read Speed: Up to 550 MB/s
Maximum Sequential Write Speed: Up to 500 MB/s
Random Read IOPS (4KB): Up to 90,000 IOPS
Random Write IOPS (4KB): Up to 85,000 IOPS
Power Consumption
Active Power Consumption: 3.0W (Typical)
Idle Power Consumption: 0.5W (Typical)
Environmental Specifications
Operating Temperature: 0°C to 70°C
Storage Temperature: -40°C to 85°C
Shock Resistance: 1500G, 0.5ms
Vibration Resistance: 5G RMS, 10-2000Hz
