K2Q16A Technical Specifications
HPE StoreFabric SN6010C 12p 16G FC Switch
Device Type : Switch – 12 Ports – Managed
Enclosure Type rack-mountable : 1u
Subtype : Fibre Channel
Ports : 12 X 16gb Fibre Channel Sfp+
Performance : Aggregate Bandwidth: 192 Gbps
Remote Management Protocol : Snmp, Snmp 3, Smi-s, Cli
Encryption Algorithm : Aes
Authentication Method : Radius, Tacacs+, Secure Shell V.2 (ssh2)
Features : Trunking, Syslog Support, Lun Zoning, Quality Of Service (qos), Redundant Hot Swappable Fans, Mac And Ip-based Acls Support
Expansion / Connectivity :
Interfaces :
12 X 16gb Fibre Channel – Sfp+
1 X Management (gigabit Lan)
1 X Management (rs-232)
Power :
Power Device : Internal Power Supply – Hot-plug
Installed Qty : 2 (installed) / 2 (max)
Power Redundancy : Yes
Power Provided : 300 Watt
Voltage Required : Ac 120/230 V (50/60 Hz)
