JL807A#ABA Technical Specifications
HPE Aruba Instant On 1960 24G 20p Class4 4p Class6
Brand: Aruba
Product Line: HPE Aruba Instant On
Model: 1960 24G 20p Class4 4p Class6 PoE 2XGT 2SFP+ 370W Switch
Manufacturer: Aruba Instant On
Clock Speed: 800 megahertz
Processor Brand: ARM
Processors Installed: 1
Authentication Method: RADIUS
Capacity: IPv4 routes (static): 32, IPv6 routes (static): 32, MAC address entries: 16000
Device Type: Internal power supply
Packaged Quantity: 1
Performance: Latency (1 Gbps): 2.2 µs, Latency (10 Gbps): 1.1 µs, Latency (100 Mbps): 4.4 µs, Switching capacity: 128 Gbps, Throughput: 95 Mpps
Ports (2nd) Quantity: 2
Ports (3rd) Quantity: 2
Form Factor (Hubs & Switches): Rack-mountable
Jumbo Frame Support: 9216 bytes
MAC Address Table Size: 16000 entries
Manageable: Yes
PoE Budget: 370 watt
Ports:24
Power Over Ethernet (PoE): PoE
Product Type: Switch
Remote Management: HTTP, HTTPS, RADIUS, SNMP 1, SNMP 2c, SNMP 3
Routing Protocol: Static IP routing
Stackable: Stackable
Status Indicators: Port status, Power
Subcategory: Network hubs and switches
Switching Type: Gigabit Ethernet
Interface Provided: 2 x 10 Gigabit Ethernet / 10 Gigabit Ethernet SFP+ SFP+, 2 x 10GBase-T RJ-45, 24 x 10/100/1000 Base-T RJ-45 370 W
Port Quantity: 24
Port Type: 10/100/1000
Ports Type (2nd): 10 Gigabit SFP+
Frequency: 50/60 hertz
Required Voltage: AC 100-240 volt
Height: 1.7 inch
Height (Rack Units): 1
Weight: 10.36 lbs
Width: 17.4 inch
Depth: 13.8 inch
