Refurbished JL319A Technical Specifications
HPE Aruba 2930M 24G 1-Slot – switch – 24 ports – managed – rack-mountable
-
Header
- Aruba
- Aruba
- HPE Aruba
- 2930M 24G 1-Slot
- 1
-
Flash Memory
- 4 GB, 4 GB
-
Performance
- Latency (10 Gbps): 3.4 µs, Latency (1 Gbps): 3.1 µs, Latency (10 Mbps): 98.5 µs, Switching capacity: 128 Gbps, Latency (100 Mbps): 11.8 µs, Throughput: 95.2 Mpps
-
Capacity
- IPv6 routing table entries: 1000, IPv4 routing table entries: 2000, Jumbo frame size: 9220
-
Networking
- Switch
- Network hubs and switches
- Gigabit Ethernet
- Rack-mountable
- Stackable
- 24
- Layer 3
- RIP, OSPFv2, IGMP, RIPng, IGMPv2, MLD, Static IPv4 routing, OSPFv3, RIP-1, CIDR, Static IP routing, IGMPv3, ECMP, OSPF, Static IPv6 routing, RIP-2
- 32768 entries
- Yes
- Telnet, RMON 1, SNMP 2c, SNMP 2, SSH, SNMP 3, SSH-2, SNMP, CLI, SNMP 1, XRMON, HTTP
- Management Information Base (MIB), Quality of Service (QoS), DiffServ support, ARP support, LLDP support, Flow control, Type of Service (ToS), DHCP support, STP BPDU Guard, Uni-Directional Link Detection (UDLD), ICMP Router Discovery Protocol (IRDP), CPU protection, MLD snooping, Class of Service (CoS), OpenFlow support, Multiple VLAN Registration Protocol (MVRP), Full duplex capability, STP Root Guard, Management Information Base (MIB) II, Spanning Tree Protocol (STP) support, SNTP support, Jumbo Frames support, BOOTP support, Virtual Extensible LAN (VXLAN), Internet Control Message Protocol (ICMP), DHCP server, IGMP snooping, Link Aggregation Control Protocol (LACP), LLDP-MED, Access Control List (ACL) support, Syslog support, Neighbor Discovery Protocol (NDP), Dynamic VLAN Support (GVRP), DHCP protection, Dynamic ARP protection, IPv6 support, MAC address lockout, VLAN support, sFlow, Multiple Spanning Tree Protocol (MSTP) support
- IEEE 802.1Q, IEEE 802.1AX, IEEE 802.3af, IEEE 802.3az, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.3bz, IEEE 802.1v, IEEE 802.1s, IEEE 802.1w, IEEE 802.1p, IEEE 802.3x
-
Ports
- 20
-
Ports (2nd)
- 4
- Combo Gigabit SFP
-
Expansion Slots
- 1 (total) / 1 (free) x expansion slot, 1 (total) / 1 (free) x Stacking Module slot
-
Interface Provided
- 1 x 1000Base-T management, 1 x serial (console), 20 x 1000Base-T RJ-45, 4 x 1000Base-T, 1 x USB Type B
-
Power Device
- Internal power supply
- 0
- 2
- AC 120/230 V
- 50/60 hertz
- 93 watt
- 80 PLUS Silver
-
Miscellaneous
- Black
- 1
- SSL, TLS, MD5
- TACACS, RADIUS, PAP, CHAP, Extensible Authentication Protocol (EAP), Secure Shell v.2 (SSH2), TACACS+
- IEC 61000-4-6, IEC 61000-4-2, IEC 61000-4-5, IEC 61000-4-4, VCCI Class A, IEC 61000-3-2, IEC 61000-4-3, CISPR 24, EN 60825-1:2007, IEC 60825-1:2007, UL 60950-1 Second Edition, IEC 61000-4-11, CSA C22.2 No. 60950-1-07 Second Edition, CISPR 22 Class A, FCC CFR47 Part 15 A, IEC 61000-4-8, EN 55022:2010, IEC60950-1:2005+A1:2009+A2:2013, ICES-003 Class A, EN 61000-3-2, EN 55024:2010, CNS 13438, EN 61000-3-3, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, IEC 61000-3-3, EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 + A1:2009 + A2:2013
