HXAF-SP-220M4S-BC Technical Specifications
Cisco Systems Ucs SP HXAF220C Hyperflex System
General Information
Product Name Ucs SP HXAF220C Hyperflex System 2XE52609V4
Manufacturer Part Number HXAF-SP-220M4S-BC
Product Line HyperFlex
Product Series HXAF220c M4
Product Type Server
Cisco UCS
Controllers
Controller Type 12Gb/s SAS
RAID Supported No
Display & Graphics
Graphics Controller Manufacturer Matrox
Graphics Controller Model G200e
Graphics Memory Capacity Up to 8 MB
I/O Expansions
Number of Total Expansion 8 Bays
Number of Internal 2.5″ Bays 8
Hot Swap Bays Yes
Memory
Standard Memory 384 GB
Maximum Memory 1.50 TB
Memory Technology DDR4 SDRAM
Number of Total Memory Slots 24 DDR4 Slots
Number of Occupied Memory Slots 12
Network & Communication
Ethernet Technology Gigabit Ethernet
Power Description
Number of Power Supplies Supported 2
Number of Power Supplies Installed 2
Maximum Power Supply Wattage 770 W
Redundant Power Supply Yes
Processor & Chipset
Number of Processors Supported 2
Number of Processors Installed 2
Processor Manufacturer Intel
Processor Type Xeon
Processor Model E5-2609 v4
Processor Core Octa-core (8 Core)
Processor Speed 1.70 GHz
Physical Characteristics
Form Factor Rack
Rack Height 1U Rack Mount
Height 1.7″
Width 19″
Depth 31″
