Refurbished HWIC-4T1/E1 Technical Specification
Cisco Clear Channel Expansion Module
Manufacturer :CISCO DS HARDWARE DIRECT
Brand :Cisco
Product Line :Cisco
Model :Clear Channel
Packaged Quantity :1
Line Properties
Line Rate :T-1/E-1
Line Coding Format :AMI, B8ZS, HDB3
Networking
Type :Expansion module
Form Factor :Plug-in module
Connectivity Technology :Wired
Data Link Protocol :FRF.16, MLPPP
Data Transfer Rate :2.048 MBps
Status Indicators :Alarm, Carrier detect
Interface Provided
Interfaces :4 x T1/E1 – RJ-48C
Miscellaneous
Compliant Standards :ACA TS001, AS/NZS 3260, CISPR 22, CISPR 24, CS-03, CSA 22.2 No. 60950, EN 300 386, EN 60950, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN300-386, EN50082-1, EN55022, EN55024, FCC CFR47 Part 15, FCC Part 68, ICES-003, IEC 60950, JATE, UL 60950, VCCI
Dimensions & Weight
Width :3.1 inch
Depth :4.7 inch
Height :0.7 inch
Weight :3.17 ounce
