G35T15KF2B2S Technical Specifications
MGE Parallel Maintenance Bypass up to 3 units
Header
Manufacturer :APC
Brand :MGE
Product Line :MGE
Model :Parallel Maintenance Bypass up to 3 units 10-15kVA
Packaged Quantity :1
General
Subcategory :Power converters, splitters and accessories
Product Type :Bypass switch
Power Device
Form Factor :External
Voltage Provided :AC 208 volt
Voltage Required :AC 208 volt
Frequency Required :60 hertz
Input Wiring :3-phase
Dimensions & Weight
Width :13.8 inch
Depth :33 inch
Height :58.7 inch
Weight :317.46 lbs
Dimensions & Weight (Shipping)
Shipping Width :28.5 inch
Shipping Depth :43.3 inch
Shipping Height :65.4 inch
Shipping Weight :451.94 lbs
Service & Support
Service & Support Details
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95%
Compatibility
Compatible With :P/N: G35T10KF1B2S, G35T10KF1B4S, G35T10KF2B2S, G35T10KF2B4S, G35T10KF3B4S, G35T10KF4B4S, G35T15KF2B2S, G35T15KF2B4S, G35T15KF3B4S, G35T15KF4B4S
