FTLX8571D3BCL Technical Specifications
Finisar SFP+ TAA Compliant Transceiver
Manufacturer: Finisar
Hot plug gable SFP+ footprint
Supports 9.95 to 10.5 Gb/s bit rates (contact Finisar for higher data rate support)
Power dissipation < 1W
Single 3.3V power supply
Maximum link length of 400m on OM4 MMF
Uncooled 850nm VCSEL laser
Receiver limiting electrical interface
LC Duplex connector
Built-in digital diagnostic functions
Product: Transceivers
Wavelength: 860 nm
Data Rate: 9.95 GBd to 10.5 GBd
Form Factor or Case Style: SFP
Emitting Source: VCSEL
Operating Supply Voltage: 3.14 V to 3.46 V
Minimum Operating Temperature: 0 C
Maximum Operating Temperature: + 70 C
Application: Ethernet
Connector Type: LC
Brand: Coherent
Mounting Style: Snap-In
Product Type: Fiber Optic Transmitters, Receivers, Transceivers
