FTLF8538P4BCL Technical Specifications
25.78Gb/s Short Wavelength SFP+ Transceiver
Up to 25.78 Gb/s bi-directional 25 Gigabit Ethernet
data links
Hot-pluggable SFP Plus footprint
Built-in digital diagnostic functions
850nm Oxide VCSEL laser transmitter
Duplex LC connector
100m over M5F MMF (50/125 um OM4)
70m over M5E MMF (50/125um OM3)
20m on MMF (50/125 m OM2)
Metal enclosure, for lower EMI
1.2W maximum power consumption
Single 3.3V power supply
Operating temperature range: 0°C t
