FMC-F20 Technical Specifications
Fortinet FortiGate 20 x Ports GE Network + 4 x Ports SX SFP transceiver Firewall
General Information
Category: Firewall appliances
Main Specifications
Header / Brand: Fortinet
Networking / Connectivity Technology: Wired
Networking / Data Link Protocol: Gigabit Ethernet
Networking / Data Transfer Rate: 1 Gbps
Networking / Form Factor: Plug-in module
Networking / Ports Qty: 20
Networking / Type: Firewall
Packaged Quantity: 1
Expansion / Connectivity
Compatible Slots: 1 x Fortinet Mezzanine Card (FMC)
Interfaces 20 x network: – Ethernet 1000 – SFP (mini-GBIC)
General
Device Type: Firewall
Miscellaneous
Included Accessories: 4 SX SFP transceivers
Networking
Connectivity Technology: Wired
Data Link Protocol: Gigabit Ethernet
Data Transfer Rate: 1 Gbps
Form Factor: Plug-in module
Network / Transport Protocol: IPSec
Performance
Firewall throughput (1518-byte packet size): 20 Gbps
Firewall throughput (512-byte packet size): 20 Gbps
Ports Qty: 20
Power
Power Consumption Operational: 59.6 Watt
