FCBG410QB1C20 Technical Specifications
4X10Gbps 20m QSFP to QSFP Active Optical Cable
Parallel 4x10Gb/s bi-directional link 40 Gigabit Ethernet
Lowest weight for high port count architectures
High-density 40Gb/s interconnectivity
20 meter cable length over Multimode (MMF)
QSFP+ form factor connectors
Applications: 40G Ethernet, InfiniBand QDR, Fibre Channel
Small bend radius for easy installation and fiber management
Thin cable for large port count architectures
Vertically integrated and highly reliable VCSEL technology
Includes Finisar’s innovative Digital Diagnostics
Supports data center link lengths of up to 100 meters
Operating case temperature range: 0°C to 70°C
