Refurbished EDU-C2960X-48FPD-L technical Specifications
Cisco Catalyst Switch 48 Ports
Manufacturer :CISCO DS HARDWARE DIRECT
Brand :Cisco
Product Line :Cisco Catalyst
Model :2960X-48FPD-L
Packaged Quantity :1
Processor
Clock Speed :600 megahertz
RAM
Installed Size :512 megabyte
Flash Memory
Installed Size :128 megabyte, 128 megabyte
Performance
Performance :Forwarding performance (64-byte packet size): 130.9 Mpps, Switching capacity: 216 Gbps
Capacity
Capacity :Virtual interfaces (VLANs): 1023
Networking
Type :Switch
Subcategory :Network hubs and switches
Subtype :Gigabit Ethernet
Form Factor :Desktop, Rack-mountable
Stackable :Stackable
Max Units In A Stack :8
Ports Qty :48
Jumbo Frame Support :9216 bytes
Manageable :Yes
Remote Management Protocol :CLI, HTTP, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet, TFTP
Power Over Ethernet (PoE) :PoE+
PoE Budget :740 watt
Status Indicators :Link/activity, PoE, Port duplex mode, Port status, Port transmission speed, RPS (Redundant Power Supply), System
Features :Access Control List (ACL) support, ARP support, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), Cisco EnergyWise technology, Cisco FlexStack Plus, Class of Service (CoS), DHCP support, Dynamic ARP Inspection (DAI), Dynamic Trunking Protocol (DTP) support, Energy Efficient Ethernet, Hot Standby Router Protocol (HSRP) support, IGMP snooping, Intrusion Detection System (IDS), IPv4 support, IPv6 support, Jumbo Frames support, Layer 2 switching, Link Aggregation Control Protocol (LACP), MAC Address Notification, MLD snooping, Multicast VLAN Registration (MVR), Multiple Spanning Tree Protocol (MSTP) support, NetFlow, PoE+, Port Aggregation Protocol (PAgP) support, Power over Ethernet (PoE), RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), SSH support, Trivial File Transfer Protocol (TFTP) support, Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), VLAN support
Compliant Standards :IEEE 802.1ab (LLDP), IEEE 802.1ae, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ports
Qty :48
Ports (2nd)
Qty :2
Type :10 Gigabit SFP+
Expansion Slots
Expansion Slots :1 (total) / 1 (free) x Stacking Module slot
Interface Provided
Interfaces :1 x 1000Base-TX RJ-45 management, 1 x console RJ-45, 1 x mini-USB mini-USB Type B – Type B management, 2 x SFP+ uplink, 2 x USB Type A, 48 x 1000Base-T RJ-45 24 ports (PoE+) / 48 ports (PoE) – 30 W
Software
Type :Cisco IOS LAN Base
Power Device
Type :Internal power supply
Power Redundancy :Optional
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
Features :Redundant Power System (RPS) connector
Miscellaneous
Color Category :Gray
Pricing Type :K-12 education
Height (Rack Units) :1
Authentication Method :Kerberos, RADIUS, Secure Shell (SSH), TACACS+
MTBF :233,370 Hours
Compliant Standards :AS/NZS 60950-1, BSMI CNS 13438 Class A, CISPR 22 Class A, CISPR 24, CSA C22.2 No. 60950-1 Second Edition, Directive 2011/65/EU, EN 300386, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC CFR47 Part 15, ICES-003 Class A, IEC 60950-1 Second Edition, KN22 Class A, KN24, RoHS, UL 60950-1 Second Edition, VCCI Class A
Dimensions & Weight
Width :17.5 inch
Depth :14.5 inch
Height :1.8 inch
Weight :12.79 lbs
