E1MG-SX-OM-8 Technical Specifications
Brocade 1000BASE-SX SFP Optic Transceiver Module
Brocade Ordering Part Number: E1MG-SX-OM-8
Manufacturing Part Number: 33210-100
Device Type: SFP
Data Rate: 1.25Gbps
Wavelength: 850nm
Distance: 550m@50/125µm OM2 MMF
Connector: Duplex LC
Cable Type: MMF
DDMI: Yes
Operating Temperature Range: 0 to 70°C (32 to 158°F)
Platform Support
Brocade SX6
Brocade 7840
Brocade 7810
