D53G-5HacD2HnD-TC&RG520F-EU Technical Specification
Mikrotik Chateau 5G R16 Router 5G Dual Band 5 Gigabit Ports
Manufacturer: MikroTik
CPU: Quad-core IPQ-4019 448-896 (auto) MHz
CPU Architecture: ARM 32bit
Size of RAM: 256 MB
Storage: 16 MB flash
1G Ethernet ports: 5
Micro SIM slots: 1
USB: port 1 USB 2.0 port type A
M.2 slot: 1
Switch chip model: IPQ-4019
Wireless: 2.4 GHz 802.11a/b/g/n dual-chain, 5 GHz 802.11a/n/ac dual-chain
Wireless antenna max gain: 2.4 GHz (3 dBi), 5 GHz (5.5 dBi)
LTE modem: R11mL-RG520F
LTE category: 20 (2.0 Gbps downlink, 200 Mbps uplink)
5G: SA Sub-6 4.0 Gbps (DL)/ 900 Mbps (UL) NSA Sub-6 4.0 Gbps (DL)/ 550 Mbps (UL)
TAC: 86945405
LTE: TDD bands 38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz) / 42 (3500MHz) / 43 (3700MHz)
3G Category: R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
3G bands: 1 (2100MHz) / 5 (850MHz) / 8 (900MHz)
Operating system: RouterOS v7 only
Operating temperature: -40°C to +70°C
