CTXP1 Technical Specifications
Dell 9207-8I 6GBPS 8 Port Int PCI-E 3.0 SAS-SATA Host Bus Adapter
Manufacturer: Dell
Part Number or SKU# CTXP1
Product Type : Controller
Product Name : SAS-SATA
Technical Information
Product: 8port Int 6gb/s Sata+sas Pcie3.0 Hba & Documentation Cd
Io Controller: Lsi Sas2308/ Fusion Mpt 2.0
Storage Connectivity Data Transfer Rates : 8ports 6gb/s Sas 2.1 Compliant
Port Configurations : 8ea X1 Ports (individual Drives) 2ea X4 Wide Port
Host Bus : X8 Lane Pci Express 3.0 Compliant
Pci Data Burst Transfer Rates : half Duplex – X8 Pcie 4000 Mb/s
Physical Dimensions : Low Profile (2.6 X 6.6)
Connectors : Two Mini-sas Internal Connectors (sff8087)
Brackets : Full Height And Low Profile
Cable Support : Passive Copper
Pci Card Type :3.3 V Add-in Card
Operating Voltage :+12v +/-8 3.3v +/-9
