CPAC-RAM64GB-23900 Technical Specifications
Check Point 64GB DDR4 SDRAM Memory Module
Manufacturer: Check Point Software Technologies, Ltd
Brand Name: Check Point
Product Name: 64GB DDR4 SDRAM Memory Module
Product Type: RAM Module
Technical Information
Memory Size: 64 GB
Memory Technology: DDR4 SDRAM
Number of Modules: 8 x 8GB
Error Checking: ECC
Signal Processing: Unbuffered
Device Supported: Security Appliance
Power Requirements
Single Power Supply rating: 800W
AC power input: 90 to 264V (47-63Hz)
Maximum thermal output: 1361.4 BTU/hr.
Dimensions
Enclosure: 2RU
Dimensions (WxDxH): 17.4×20.84×3.5 in. (442x529x88mm)
Weight: 34.8 lbs. (15.8 kg)
Environmental Conditions
Operating: 0° to 40°C, humidity 5% to 95%
Storage: –20° to 70°C, humidity 5% to 95% at 60°C
Physical Characteristics
Number of Pins: 288-pin
Form Factor: DIMM
Miscellaneous
Compatibility: Check Point 23900 Security Appliance
