C9300L-24T-4G-10A Technical Specifications
Cisco Systems C9300L 24-Port Data 4X1G Network Advant
Manufacturer Part Number: C9300L-24T-4G-10A
Product Type: Ethernet Switch
Manageable: Yes
Ethernet Technology: Gigabit Ethernet
Number of Total Expansion Slots: 4
Product Family: Catalyst 9300
Stack Port: Yes
Media Type Supported: Twisted Pair, Optical Fiber
Total Number of Network Ports: 24
Redundant Power Supply Supported: Yes
Expansion Slot Type: SFP
Form Factor: Rack-mountable
Input Receptacles: IEC 60320 C14
Power Consumption: 350 W
Power Source: Power Supply
Layer Supported: 3
Environmentally Friendly: Yes
Number of Power Supplies Supported: 2
Number of Power Supplies Installed: 1
Number of SFP Slots: 4
Modular: Yes
Uplink Port: Yes
Height: 1.7″
Width: 17.5″
Depth: 17.7″
Product Series: 9300
Product Model: C9300L-24T-4G
Input Voltage: 120 V AC, 230 V AC
Frequency: 50 Hz, 60 Hz
