C9300-24U-E-UL Technical Specifications
Cisco Systems Catalyst 9300 24-Port Upoe Network Esse
Manufacturer Part Number: C9300-24U-E-UL
Product Type: Ethernet Switch
Manageable: Yes
Ethernet Technology: Gigabit Ethernet, 10 Gigabit Ethernet
Number of Total Expansion Slots: 1
Product Family: Catalyst 9300
Stack Port: Yes
Media Type Supported: Twisted Pair, Optical Fiber
Total Number of Network Ports: 48
PoE (RJ-45) Port: Yes
Redundant Power Supply Supported: Yes
Expansion Slot Type: Uplink Module
Plug / Connector Type: IEC 60320 C16, IEC 60320 C14, C15
Form Factor: Rack-mountable
Power Consumption: 1100 W
Power Source: Power Supply
Layer Supported: 3
Environmentally Friendly: Yes
Compatible Rack Unit: 1U
Number of Power Supplies Installed: 1
Modular: Yes
Uplink Port: Yes
PoE Budget: 830 W
Height: 1.7″
Width: 17.5″
Depth: 19.2″
Product Series: 9300
Product Model: C9300-24U
