C9200L-48PXG-4X-A Technical Specifications
Cisco Catalyst 9200L Network Advantage switch 48 port
Capacity
Type :ACL scale entries
Type :FNF entries
Value :16000
Type :IPv4 routes
Value :11000
Type :IPv4 routing table entries
Value :3000
Type :IPv6 routing table entries
Value :1500
Type :Multicast scale
Value :1000
Type :Packet buffer size
Value :6 MB
Type :QoS hardware queues per port
Value :8
Type :Switched virtual interfaces (SVIs)
Value :512
Type :Virtual networks
Value :1
Type :VLANs supported
Value :1024
Dimensions & Weight
Depth :13.8 in
Height :1.7 in
Weight :12.59 lbs
Width :17.5 in
Environmental Parameters
Humidity Range Operating :5 – 90% (non-condensing)
Humidity Range Storage :5 – 90% (non-condensing)
Max Operating Temperature :113 °F
Max Storage Temperature :158 °F
Min Operating Temperature :23 °F
Min Storage Temperature :-40 °F
Flash Memory
Installed Size :4 GB
