C9200-48P-EDU Technical Specifications
Cisco Catalyst 9200 Switch 48 Port Managed Rack Mountable
Capacity
Type : Flexible NetFlow entries
Value : 16000
Type : IPv4 routing table entries
Value : 4000
Type : IPv6 routing table entries
Value : 2000
Type : Packet buffer size
Value : 6 MB
Type : Switched virtual interfaces (SVIs)
Value : 1000
Type : Virtual networks
Value : 4
Type : VLAN IDs
Value : 4096
Dimensions & Weight
Depth : 13.8 in
Height : 1.7 in
Weight : 12.13 lbs
Width : 17.5 in
Environmental Parameters
Humidity Range Operating : 5 – 90% (non-condensing)
Humidity Range Storage : 5 – 90% (non-condensing)
Max Operating Temperature : 113 °F
Max Storage Temperature : 158 °F
Min Operating Temperature : 23 °F
Min Storage Temperature : -40 °F
Flash Memory
Installed Size : 4 GB
Header
Brand : Cisco
Manufacturer : CISCO DS HARDWARE DIRECT
Model : 9200
Packaged Quantity : 1
Product Line : Cisco Catalyst
