Refurbished C888-K9 Technical Specification
Cisco 888 G.SHDSL Router With Cube Router
Manufacturer :CISCO DS HARDWARE DIRECT
Brand :Cisco
Product Line :Cisco
Model :888 G.SHDSL Router with CUBE
Packaged Quantity :1
RAM
Installed Size :256 megabyte
Flash Memory
Installed Size :128 megabyte, 128 megabyte
Modem
Type :DSL modem
Protocols & Specifications :ITU G.991.2 (G.shdsl)
Capacity
Capacity :IPSec VPN tunnels: 20, Maximum number of configured SSIDs: 16, Wireless VLANs: 8
Networking
Type :Router
Form Factor :Desktop
Connectivity Technology :Wired
WAN Ports Qty :2
Integrated Switch :4-port switch
Data Link Protocol :Ethernet, Fast Ethernet
Wireless Protocol :802.11b/g/n (draft 2.0)
Routing Protocol :GRE, HSRP, Policy-based routing (PBR), RIP-1, RIP-2, VRRP
Network / Transport Protocol :DNS, FTP, IPSec, L2TP
Remote Management Protocol :CLI, HTTP, HTTPS, SNMP 3, SSH, Telnet
Status Indicators :Port status, Power
Key Features :Firewall, USB port, VPN support
Features :2T3R MIMO technology, Broadcast Storm Control, Call Admission Control (CAC), Class of Service (CoS), Class-Based Weighted Fair Queuing (CBWFQ), DHCP client, DHCP relay, DHCP server, DiffServ Code Point (DSCP) support, DNS proxy, Dynamic Multipoint VPN (DMVPN), Firewall protection, Hot Standby Router Protocol (HSRP) support, Intrusion Prevention System (IPS), Low-latency queuing (LLQ), MAC address filtering, Management Information Base (MIB), MDI/MDI-X switch, Multicast Storm Control, NAT support, Port Security, Quality of Service (QoS), Spanning Tree Protocol (STP) support, Unicast Storm Control, Virtual Route Redundancy Protocol (VRRP) support, VLAN support, VPN support, Weighted Fair Queuing (WFQ), Wi-Fi Multimedia (WMM) support
Compliant Standards :IEEE 802.11i, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3af, Wi-Fi CERTIFIED
Interface Provided
Interfaces :LAN: 4 x 10Base-T/100Base-TX – RJ-45, Management: 1 x console – RJ-45, USB: 1 x 4 pin USB Type A, WAN: 1 x BRI ST – RJ-45, WAN: 1 x SHDSL
Power Device
Type :External power adapter
Power Provided :60 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
Miscellaneous
Color Category :Gray
Encryption Algorithm :128-bit AES, 192-bit AES, 256-bit AES, DES, LEAP, PEAP, PKI, SSL, TKIP, TLS, Triple DES, TTLS, WEP, WPA, WPA2
Authentication Method :EAP-FAST, Radio Service Set ID (SSID), RADIUS, TACACS+
Compliant Standards :AS/NZS 3548 Class B, CISPR 22, CISPR 24, EN 300 386 V1.3.3, EN 300386, EN 60555-2, EN 61000-3-2, EN 61000-3-3, EN50082-1, EN55022, EN55022 Class B, EN55024:1998 + A1 + A2, FCC CFR47 Part 15, FCC CFR47 Part 15 B, ICES-003, ICES-003 issue 4 Class A, IEC 61000-6-1:2005, KN22, VCCI V-3
Dimensions & Weight
Width :12.8 inch
Depth :9.8 inch
Height :1.7 inch
Weight :5.51 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :10 – 85% (non-condensing)
