C1861E-SRST-F/K9 Technical Specifications
Cisco 1861E 8-Ports Integrated Services
Brand: Cisco
Product Condition: New
Manufacturer Cisco Systems, Inc
Manufacturer Part Number C1861E-SRST-F/K9
Brand Name Cisco
Network / Transport Protocol : IPSec
Routing Protocol : GRE
Remote Management Protocol : SNMP 3, HTTP, SSH-2
Authentication Method : Secure Shell v.2 (SSH2)
Features
Firewall protection, NAT support, power over Ethernet (PoE), VLAN support, Intrusion Prevention System (IPS), URL filtering, IPSec Virtual Private Network (VPN), Quality of Service (QoS), Dynamic Multipoint VPN (DMVPN)
Compliant Standards
IEEE 802.3af, IEEE 802.1x, VCCI, CISPR 24, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, EN50082-1, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, FCC Part 15, CS-03, EN 61000-4-5, CSA C22.2, EN 61000-6-2, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, BSMI CNS 13438, EN 300 386
Memory
RAM : 512 MB
Flash Memory : 256 MB
IP Telephony
VoIP Functionality : VoIP gateway
Voice Codecs : G.711, G.729
Telephony Interfaces : 4 phone (FXS), 4 line (FXO)
Expansions And Connectivity
Interfaces
WAN: 1 x 10Base-T/100Base-TX – RJ-45 LAN: 8 x 10Base-T/100Base-TX – RJ-45 WAN: 1 x 10Base-T/100Base-TX – RJ-45 Audio: 1 x mini-phone 3.5 mm Phone line: 4 x FXS – RJ-11 Phone line: 4 x FXO – RJ-11 Management
