C1-N9KC93180FX-B24 Technical Specifications
Cisco ONE Nexus 93180YC-FX – PID Bundle Switch 48 ports Managed
Interface Provided
Comments : Downlink
Connector Type : SFP+
Qty : 48 SFP+
Type : 1/10/25Gbit LAN / 8/16/32Gb Fibre Channel
Comments : Uplink
Connector Type : QSFP28
Qty : 6
Type : 100Gbit/40Gbit LAN
Connector Type : RJ-45
Qty : 1
Type : Management
Type : Serial (RS-232)
Type : USB
Networking
Advanced Switching : Layer 3
Compliant Standards : IEEE 802.1ae
Features : 4 fans, 40MB system buffer, Access Control List (ACL) support, Ethernet Virtual Private Network (EVPN), MACsec support, Multiple Spanning Tree Protocol (MSTP) support, Power On Auto Provisioning (POAP), Source-Specific Multicast (SSM), Spanning Tree Protocol (STP) support, Virtual Extensible LAN (VXLAN), Virtual PortChannel (vPC) technology
Form Factor : Rack-mountable
MAC Address Table Size : 512K entries
Manageable : Yes
Ports Qty : 48
