Refurbished C1-ASR1001-X/K9 Technical Specifications
Cisco ONE – ASR1001-X with 6 x SFP , 2 x SFP+
Physical specifications
Refer to the applicable hardware installation guide for additional details.
Height: 1.71 in. (43.43 mm)
Width: 17.3 in. (439.42 mm)
Depth: 18.17 in. (461.5 mm)
Weight:
25 lb (11.35 kg) fully loaded
Note: The Cisco ASR 1001-X Router has the route processor, ESP, and SIP integrated.
Default memory
8-GB DRAM shared across route processor, ESP, and SIP
Number of SIPs or Ethernet line cards supported
Integrated in chassis
Shared port adapters
1 single-height SPA slot
Ethernet port adapters
N/A
Cisco ASR 1000 Series ESP
Integrated in chassis
Route processor
Integrated in the chassis: Cisco ASR 1001-X Series Route Processor with Quad Core Processor
Redundancy
Software: Yes
Built-in Gigabit Ethernet ports
Yes: 6 Gigabit Ethernet Small Form-Factor Pluggable (6 SFP) ports
Built-in 10 Gigabit Ethernet port
Yes: Two 10 Gigabit Ethernet Small Form-Factor Plus Pluggable (2 SFP+) ports
Note:Built-in 10-GB ports cannot be reduced to 1-GB speed.
Network interface module
Yes
Cisco ASR 1000 Series
Cisco ASR 1001-X
ESP support
Cisco ONE ASR
Cisco ASR 1000 Series 2.5-Gbps ESP (default)
Upgradable through a software-activated feature license to 5, 10, or 20 Gbps
ESP bandwidth
2.5 to 20 Gbps
ESP memory
Share the same control memory on route processor
SIPs and Ethernet line cards
Integrated in chassis; not upgradable
Embedded hardware-based encryption
Yes: Up to 8-Gbps crypto support throughput
Minimum Cisco IOS XE Software release
Cisco IOS XE Software Release 3.12.0
Rack-mounting
Yes: 19-inch
Wall-mounting
No
External USB flash memory
1-GB USB flash-memory support
Redundant power supply
Yes: Dual power supplies by default; option of either AC or DC power supply
Note: A mix of one AC and one DC power supply is not supported.
Power input
Worldwide ranging AC input range (85 to 264 VAC)
Worldwide ranging DC
(-40 to -72V; 48V nominal)
Power consumption
● Maximum (DC): 242W
● Maximum (AC): 250W
● Maximum (out): 250W
Airflow
Front-to-back
Operating temperature (nominal)
32 to 104°F
0 to 40°C)
Operating temperature (short-term)
32 to 122°F
0 to 50°C)
Operating humidity (nominal) (relative humidity)
10 to 85%
Operating humidity (short-term)
5 to 90%
Storage temperature
-40 to 150°F
(-40 to 70°C)
Storage humidity (relative humidity)
5 to 95%
Operating altitude
-500 to 10,000 feet
152 to 3048 meters)
Network Equipment Building Standards (NEBS)
GR-1089 and GR-63 (in progress)
EMC standards
● FCC 47 CFR Part 15 Class A
● VCCI Class A
● AS/NSZ Class A
● ICES-003 Class A
● EN55022/CISPR 22 Information Technology Equipment
(Emissions)
● EN55024/CISPR 24 Information Technology Equipment
(Immunity)
● EN300 386 Telecommunications Network Equipment
● (EMC)
● EN50082-1/EN61000-6-1 Generic Immunity Standard
Safety Standard
UL60950-1
CSA C22.2 No. 60950-1-03
EN 60950-1
IEC 60950-1
AS/NZS 60950.1
