HP ProLiant BL460c G10 Technical Specifications
Blade Server – 1 x Intel Xeon Silver 4108 Octa-core (8 Core) 1.80 GHz – 16 GB Installed DDR4 SDRAM – Serial ATA Controller
General
Type Server
Product Form Factor Blade
Built-in Devices Led panel
Server Scalability 2-way
Hot-Swap Bays Qty 2
Processor / Chipset
CPU Intel Xeon Silver 4108 / 1.8 GHz
Number of Cores 8-core
CPU Qty 1
Max CPU Qty 2
CPU Upgradability Upgradable
Processor Main Features Hyper-Threading Technology, Intel Turbo Boost Technology
CPU Socket Socket P
Chipset Type Intel C621
Cache Memory
Installed Size L3 Cache – 11 MB
Cache Per Processor 11 MB
RAM
Installed Size 16 GB / 768 GB (max)
Technology DDR4 SDRAM
Effective Memory Speed 2400 MHz
Rated Memory Speed 2666 MHz
Memory Specification Compliance PC4-20800
Form Factor DIMM 288-pin
Slots 8 (Total) / 6 (empty)
Features Registered, dual rank, slots 9 – 16 are available in two-processor configuration only
Configuration Features 2 x 8 GB (2 DDR4 Slots)
RAM Supported PC4-20800 – 1.024 TB Load-Reduced
PC4-20800 – 512 GB registered
Hard Drive
Type No HDD
Storage Controller
Type 1 x SATA
Controller Interface Type SATA 6Gb/s
Storage Controller Name HPE Smart Array S100i SR Software
Optical Storage
Type No optical drive
Card Reader
Type Card reader
Supported Flash Memory Cards microSDHC
Monitor
Monitor Type None.
Graphics Controller
Graphics Processor Matrox G200eH
Video Memory 16 MB
Networking
Interface (Bus) Type FlexibleLOM
Ethernet Ports 2 x 10 Gigabit Ethernet
Ethernet Controller HP FlexFabric 536FLB
Data Link Protocol Gigabit Ethernet, 10 Gigabit Ethernet, 10Gb Fibre Channel over Ethernet (FCoE)
Remote Management Protocol SNMP, IPMI 2.0, SMASH CLP
Remote Management Controller Integrated Lights-Out 4
Features Wake on LAN (WoL), PXE support
Compliant Standards IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.1ab (LLDP), IEEE 802.3ap, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg
Expansion / Connectivity
Bays 2 (total) / 2 (free) x hot-swap 2.5″ SFF
Slots 1 (total) / 0 (free) x FlexibleLOM
2 (total) / 2 (free) x PCIe 3.0 x16
2 expansion slot (x16 mode)
1 (total) / 1 (free) x microSDHC Card (internal)
2 (total) / 1 (free) x CPU
8 (total) / 6 (free) x DIMM 288-pin
Interfaces 1 x HP iLO – Type A (1 in front)
1 x USB 3.0 (1 internal)
1 x LAN – RJ-45 (HPE iLO 5 to Onboard Administrator link)
2 x LAN (10Gigabit Ethernet)
Miscellaneous
Included Accessories 2 x blanking panels
Compliant Standards ACPI 6.1
Operating System / Software
OS Certified CentOS, Microsoft Windows Server 2012 R2 Datacenter, Microsoft Windows Server 2012 R2 Standard, Microsoft Windows Server 2012 with Hyper-V, Microsoft Windows Server 2016, Microsoft Windows Server 2012 R2 with Hyper-V, SuSE Linux Enterprise Server 12 SP3, Citrix XenServer 7.0, Microsoft Windows Server 2016 with Hyper-V, Red Hat Enterprise Linux 6.9, VMware vSphere 6.5, SuSE Linux Enterprise Server 12 SP2, Red Hat Enterprise Linux 7.4, Citrix XenServer 7.1
Software HPE Server UEFI
Dimensions & Weight
Width 5.54 cm
Depth 51.76 cm
Height 18.07 cm
Weight 4.75 kg
Environmental Parameters
Min Operating Temperature 10 °C
Max Operating Temperature 35 °C
Humidity Range Operating 10 – 90% (non-condensing)
