Refurbished ASA5515-DC-K8 Technical Specification
Cisco ASA 5515-X 6Gbe Data 1Gbe
Networking
Form Factor Rack-mountable
Ports Qty 6
Connectivity Technology Wired
Data Link Protocol Gigabit Ethernet
Performance Firewall throughput: 1.2 Gbps ¦ VPN throughput (3DES/AES): 250 Mbps ¦ Connection rate: 15000 connections per second ¦ Firewall + intrusion prevention throughput: 400 Mbps
Capacity IPSec VPN peers: 250 ¦ SSL VPN peers: 2 ¦ Concurrent sessions: 250000 ¦ Virtual interfaces (VLANs): 100 ¦ Security contexts: 2
Status Indicators Power, HDD activity, active, alarm
Features Firewall protection, VPN support, VLAN support
Encryption Algorithm DES
Max Operating Temperature 104 °F
Humidity Range Operating 10 – 90% (non-condensing)
General
Device Type Security appliance
Height (Rack Units) 1U
Width 16.9 in
Depth 15.6 in
Height 1.7 in
Weight 13.45 lbs
Processor / Memory / Storage
RAM 8 GB
Expansion / Connectivity
Expansion Slots 1 (total) / 1 (free) x expansion slot
Interfaces 6 x 1000Base-T – RJ-45 ¦ 1 x 1000Base-T (management) – RJ-45 ¦ 1 x management – RJ-45 ¦ 2 x USB 2.0 – Type A
Power
Power Device Internal power supply
Installed Qty 1
Max Supported Qty 1
Voltage Required DC -48/-60 V
Software / System Requirements
Software Included Drivers & Utilities
