AOC-SAS3-9300-8E Technical Specifications
Supermicro Storage controller SAS 12Gb/s PCIe 3.0
Brand: Supermicro
Dimensions: 16.8cm x 6cm
Controller Type: HBA
Data Transfer Rates: 12Gb/s SAS-3
External Ports: 8
Interface: PCIe 3.0 x8
PCI Power: 14.5 Watt
I/O Controller: SAS3008
Brackets: Full height and low profile
Operating Environment
Operating Temperature: 0°C to 55°C
Host Bus Type: x8 lane PCI Express® 3.0
Devices Supported: 1024 Non-RAID SAS/SATA devices
External Connectors: 2 Mini-SAS HD SFF8644
Fusion MPT Support Fusion MPT™ 2.5
Operating Voltage (V): +12V +/-8%, 3.3V +/-9%
Cable Support: Passive Copper, Active Optical
Brackets: Full height and low profile vented
Data Transfer Rates: 12Gb/s SAS-3 Compliant
Management Software: MegaRAID Storage Manager (MSM), StorCLI (Command-Line Interface), LSI Storage Authority (LSA), HII UEFI Human Interface Infrastructure), CTRL-R
