AL400ULXPD16 Technical Specifications
ALTRONIX 16Fuse 12Dc/3.5A Or 24Dc/3A Power Supply/Charger
Manufacturer: Altronix
Manuf Part#: AL400ULXPD16
Product Type: Proprietary Power Supply
Number of +12V Rails: 16
Product Family: AL400ULPD
Form Factor: Wall Mount
Product Model: AL400ULXPD16
Input Voltage: 110 V AC
Output Voltage: 12 V DC , 24 V DC
Environmentally Friendly: Yes
Output Voltage Detail: 12 V DC @ 4 A , 24 V DC @ 3 A
Height: 15.5″
Width: 12.2″
Depth: 4.5″
Product Series: AL400ULPD
Output Current: 4 A , 3 A
Protection Type: Fuse , Short Circuit , Thermal Overload
Limited Warranty: Lifetime
Input Voltage Type: AC
NDAA Compliant: Yes
Input Current: 1.45 A @ 110V
Number of Connections: 16
