AF60-LR Technical Specifications
Ubiquiti airFiber 60 LR
Brand: Ubiquiti Networks
Manufacturer: Ubiquiti Networks
Dimensions: 413 x 413 x 360 mm (16.3 x 16.4x 14.2″)
Enclosure: Aluminum, UV-stabilised Polycarbonate
Hardware
Processor: Quad-Core ARM Cortex A7
Memory: 256 MB DDR3
Networking Interface: 10/100/1000 Mbps RJ45 Ethernet
RF Connections: Internal
Max. Power Consumption: 18WPower
Method: Passive PoE (Pairs 4, 5+; 7, 😎
Power Supply: 48VDC, 0.65A Gigabit PoE Adapter
Supported Voltage Range: 48VDC ± 10%
ESD/EMP Protection: Air/Contact: ± 24kV
Operating Temperature: -40 to 60° C (-40 to 140° F)
Operating Humidity: 5 to 95% Noncondensing
Certifications: FCC, IC, CE
GPS: Blue: Receiving at Least (4) GPS Satellite Signals
60G: Blue: Active Connection
System
Maximum Throughput:1.8 Gbps
Maximum Range:12 km
Encryption: WPA2-PSK (AES)
Software
OS:airOS®
Services: UISP, Ping Watchdog, NTP Client, System Log
Utilities: Antenna Alignment Tool, Discovery Utility, Ping, Traceroute, Speed Test
Network: Bridge Mode
Technology: Wave
