AB202855 Technical Specification
Dell Network Management Card 3 with Powerchute
Manufacturer: Dell
Brand: Dell
Device Type: Remote Management Adapter
Technical Information
Form Factor: Plug-in Module
Connectivity Technology: Wired
Cabling Type: Ethernet 10base-t, Ethernet 100base-tx, Ethernet 1000base-t
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate: 1 GBPS
Features: Ipv6 Support, Radius Support, Ipv4 Support
Operating Temperature: 32- 113 °f (0 – 45 °c)
Operating Relative Humidity: 0 – 95 %
Operating Elevation: 0-10000ft (0-3000meters)
Storage Temperature: 5-45 °c
Storage Relative Humidity: 0- 95 %
Storage Elevation: 0-50000ft (0-15000meters)
Network / Transport Protocol: Tcp/ip, Smtp
Remote Management Protocol: Snmp 1, Telnet, Snmp 3, Snmp 2c, Http, Https, Ssh, Ssh-2
Dimensions & Weight
Height: 1.5 Inch
Width: 4.76 Inch
Depth: 4.49 Inch
Weight: 0.18 LBS
